C14 4MP Cube Wi-Fi Network Camera

A compact, 4MP cube-style Wi-Fi network camera featuring true day/night IR vision, PIR motion detection, dual-streaming, 2-way audio, and remote access via mobile app or web. Designed for flexible indoor deployment with wall, ceiling, or desktop mounting options.

Product Features:

• Max resolution: 4MP (2560×1440)

• ICR auto switch (true day/night vision)

• 0.3–10m IR night view range

• 2.4G Wi-Fi support (IEEE802.11 b/g/n)

• Motion, PIR, and audio alarms

• Human/vehicle classification

• Two-way audio with built-in MIC and speaker

• Dual stream support

• SD card storage (up to 256GB)

• Mobile app access (snapshot, playback, sharing)

• PoE or DC12V powered

• Support P2P and ONVIF protocol

Technical Specifications:

Camera:

• Sensor: 1/3″ Progressive Scan CMOS

• Resolution: 2560×1440

• Lens: 2.1mm @F2.1, HFOV: 137°

• WDR: 78dB

• IR Distance: 0.3–10m

• DNR: 2D/3D

• Angle Adjustment: Pan 0–230°, Tilt 0–71°, Rotate 0–360°

Video:

• Compression: H.265+/H.265/H.264+/H.264, MJPEG (sub stream)

• Streams: Dual stream

• Bitrate: 64Kbps–6Mbps (VBR/CBR)

• Frame rate: Up to 30fps

• Resolutions supported: 4MP down to CIF

Audio:

• Compression: G711 A/U

• Built-in MIC and speaker (with echo cancellation)

• Two-way audio supported

Network:

• Interface: 100M RJ45 Ethernet

• Protocols: IPv4/IPv6, RTSP, HTTP, ONVIF, P2P, UPnP, etc.

• Wi-Fi: 2.4GHz, range up to 50m

Smart Functions:

• Intelligent Analytics: Line crossing, region intrusion (human/vehicle classification)

• Alarms: Motion, PIR, audio, person detection, SD errors/full, cable disconnection, IP conflict

Storage:

• Built-in SD card slot (up to 256GB)

• Network remote storage

Security:

• Video/configuration/firmware encryption

• IP filtering, illegal login lock, HTTPS, 802.1x, API authentication

General:

• Power: DC12V or PoE (IEEE802.3af)

• Consumption: <5W

• Environment: -20°C to 50°C, <95% humidity

• Dimensions: 130 × 71.7 × 71.7 mm

• Weight: ~0.14kg

• Installation: Wall, ceiling, or desktop

• Environmental Compliance: RoHS 2.0, REACH, WEEE, 94/62/EC
