TD-9525S4-C 2MP Dual Illumination Water-proof Turret Network Camera

TD-9525S4-C is a professional-grade 2MP turret IP camera designed for high-quality video surveillance in various lighting conditions. It features dual illumination (white light + IR), smart detection capabilities, and excellent protection for harsh environments. This camera supports remote access, smart analytics, and delivers real-time performance through multiple video streams and efficient compression standards.

Product Features

• H.265+ / H.265 / H.264+ / H.264 / MJPEG encoding

• Max. resolution: 2MP (1920 × 1080)

• Day/night auto switch with ICR

• Smart IR and white light (30–40m each)

• 3D DNR, HWDR (120dB), HLC, BLC

• ROI coding

• Triple stream support

• Built-in microphone and 1CH audio input

• DC12V or PoE power supply (IEEE802.3af)

• IP67-rated waterproof housing

• Support P2P, mobile monitoring (iOS & Android)

• Smart event detection: line crossing, region intrusion, object loss/detection, motion detection, SMD

• Advanced security: video/configuration encryption, HTTPS, IP filtering

• Up to 256GB microSD local storage

• VCA (Video Content Analysis), disarming, corridor mode

Technical Specifications

Camera

• Image Sensor: 1/2.8″ CMOS

• Image Size: 1920 × 1080

• Electronic Shutter: 1/3s ~ 1/100000s

• Min. Illumination: 0.006 lux @F1.4, AGC ON; 0 lux (IR or white light on)

• Lens: 2.8~12mm @F1.4 varifocal

  • H FoV: 98°–33°, V FoV: 52°–20°, D FoV: 120°–40°

• Lens Mount: Ø14

• Wide Dynamic Range: 120dB (HWDR)

• BLC / HLC / DNR: Supported

• Day/Night: ICR (mechanical switch)

• Angle Adjustment:

  • Pan: 0°–360°

  • Tilt: 0°–80°

  • Rotation: 0°–360°

• S/N Ratio: ≥50dB

Video

• Compression: H.265+, H.265, H.264+, H.264, MJPEG

• H.265 Profile: Main Profile @ Level 4.1 High Tier

• Resolutions: 1080P, 720P, D1, VGA, 640×480, 480×240, CIF

• Streams:

  • Main: 1080P/720P (130fps at 60Hz, 125fps at 50Hz)

  • Sub: D1/480×240/CIF

  • Third: D1/VGA/CIF

• Bitrate: 64 Kbps ~ 6 Mbps

• Bitrate Type: VBR / CBR

• Image Settings: Brightness, Contrast, Saturation, Hue, WDR, Sharpness, Mirror, Flip, NR

• ROI: Configurable per zone

Audio

• Input: 1 channel

• Built-in Mic: Yes

• Compression: G711A/U

Interfaces

• Network: RJ45 (10/100 Base-T)

• Video Output: None

• Storage: microSD slot (up to 256GB)

• Reset Button: Yes

Functions

• Remote Monitoring:

  • Via browser, TVT NVR, NVMS 2.X, Mobile App

• Simultaneous Users: Up to 6

• Web Browsers Supported: Chrome 89+, Edge 89+, Firefox 87+, Safari 14+

• Network Protocols:

  • UDP, DHCP, NTP, RTSP, RTP, RTCP, RTMP, PPPoE, DDNS, IPv4/IPv6, SMTP, FTP, 802.1x, SNMP, UPnP, HTTPS, HTTP POST, P2P, QoS

• Interface Protocol: ONVIF

• API & SDK: Supported

• Storage Options: Local (microSD) and network

Smart Alarms & Events

• Motion detection, SMD

• Line crossing, region intrusion (human/vehicle detection)

• Abandoned/missing object

• Video exception, SD card full/error, IP conflict, network loss

Security

• Encryption: video, firmware, config, HTTPS

• Login lock, IP address filtering, 802.1x auth

• HTTP/RTSP basic and digest authentication

Illumination

• IR Range: 30–40 meters

• White Light Range: 30–40 meters

• Supplement Light Control: Smart mode

Environment & Installation

• Power Supply: DC12V or PoE

• Power Consumption:

  • DC12V: <6.9W

  • PoE: <8.8W

• Operating Temp: -30°C ~ 60°C

• Storage Temp: -30°C ~ 65°C

• Humidity: <95% (non-condensing)

• Ingress Protection: IP67

• Installation: Ceiling or wall mounting

• Dimensions: Φ111.6 × 99.6 mm

• Weight: Approx. 0.66 kg

Certifications & Compliance

• CE, FCC

• RoHS, WEEE (2012/19/EU), Directive 94/62/EC, REACH (EC1907/2006)
