TD-9544S4L-C 4MP Dual Illumination Waterproof Turret Network Camera

Technical Specifications

Camera

• Image Sensor: 1/3″ CMOS

• Image Size: 2560 × 1440

• Electronic Shutter: 1/3s ~ 1/100000s

• Iris Type: Fixed Iris

• Lens:

  • 2.8mm@F2.2, FoV: H: 96°, V: 53.7°, D: 112°

  • 3.6mm@F2.2, FoV: H: 74.5°, V: 41.5°, D: 86.5°

• Focus: Fixed

• Lens Mount: M12

• Min. Illumination: 0.09 lux @F2.2 (AGC ON); 0 lux (IR on)

• Day & Night: ICR

• Wide Dynamic Range: Digital WDR

• 3D DNR / BLC / HLC: Yes

• S/N Ratio: ≥50dB

• Angle Adjustment: Pan: 0°~360°, Tilt: 0°~75°, Rotation: 0°~360°

Video

• Compression: H.265+ / H.265 / H.264+ / H.264 / MJPEG

• H.265 Profile: Main Profile@Level 4.1 High Tier

• Resolution Options:

  • 4MP (2560×1440), 3MP, 1080P, 720P, D1, VGA, 480×240, CIF

• Frame Rate:

  • Main Stream: 130fps (60Hz), 125fps (50Hz)

  • Sub Stream: 130fps (60Hz), 125fps (50Hz)

• Bitrate: 64 Kbps ~ 3 Mbps (VBR / CBR)

• Audio Compression: G711A/U

• Image Settings: ROI, brightness, contrast, sharpness, mirror/flip, etc.

• ROI: Multiple configurable areas

Interfaces

• Network: RJ45 (10/100 Base-T)

• Audio: Built-in mic

• Storage: No local storage

• Reset: Yes

Functions

• Remote Monitoring: Via browser, TVT NVR, NVMS 2.X, or mobile app

• Browser Support: IE11 (plugin), Chrome 89+, Edge 89+, Firefox 87+, Safari 14+

• Concurrent Users: Up to 3 simultaneous

• Network Protocols: UDP, IPv4/IPv6, DHCP, NTP, RTSP, 802.1x, HTTP

• Interface Protocol: ONVIF

• Motion Detection: Smart (filters non-human movement)

• Smart Events: Human-based line crossing & region intrusion

• General Function: Watermark, heartbeat, video mask

• Security: Encryption, login lock, IP filtering, 802.1x, HTTP auth

Power and Environmental

• Power Supply: DC12V or PoE (IEEE802.3af)

• Power Consumption: < 5W

• Operating Temp: -30°C ~ 60°C (-22°F ~ 140°F), <95% RH

• Storage Temp: -30°C ~ 65°C (-22°F ~ 149°F), <95% RH

• Dimensions: Ø94.6 × 82.8 mm

• Weight: Approx. 0.42 kg

• Installation: Ceiling or wall mount

• Ingress Protection: IP67

• Certification: CE, FCC, RoHS, WEEE, REACH compliant
